Drill Pipe Power Tong

XQ series tubing power tong (Inner curved cam clamp)  is used for quick make-up/ break-out in well service operations. The tong is equipped with hydraulic backup tong and use inner curved cam to clamp. The tongs have the following features:



n  Clamp the tubing use corresponding dies, jaw set or die seat.

n  Torque control valve may be equipped according to customer’s request.

n  Choose and buy lengthening guide pole assembly, the backup tong can clamp the tubing body.

n  Torque control system may be equipped according to customer’s request.



On inquiries and orders please specify:

n  Size Range of the drill pipes

n  Torque Value

n  Pressure Value



Remark:

1. To clamp the 2 3/8” tubing, special dies must be ordered for Model XQ 89/3YB, 3YC;

2. Advantage of Model XQ89/3YE; Low speed, rated speed is 28 rpm. Dies of backup tong can clamp the underside of tubing coupling, so as to reduce distortion of tubing coupling to prevent conglutination of thread.


XQ series tubing power tong (Inner curved cam clamp)  is used for quick make-up/ break-out in well service operations. The tong is equipped with hydraulic backup tong and use inner curved cam to clamp. The tongs have the following features:



n  Clamp the tubing use corresponding dies, jaw set or die seat.

n  Torque control valve may be equipped according to customer’s request.

n  Choose and buy lengthening guide pole assembly, the backup tong can clamp the tubing body.

n  Torque control system may be equipped according to customer’s request.



On inquiries and orders please specify:

n  Size Range of the drill pipes

n  Torque Value

n  Pressure Value



Remark:

1. To clamp the 2 3/8” tubing, special dies must be ordered for Model XQ 89/3YB, 3YC;

2. Advantage of Model XQ89/3YE; Low speed, rated speed is 28 rpm. Dies of backup tong can clamp the underside of tubing coupling, so as to reduce distortion of tubing coupling to prevent conglutination of thread.
