TSB series centrifugal sand pump mainly supplies to solids control circulating system of oilfield drill rig, and be used to provide drilling liquid with a certain discharge capacity and pressure to desander, desilter and mud mixer, to assure these equipments work efficiently.
The TSB10×8×14 centrifugal sand pump applies to over 3000-meter-long drilling rigs, with big viscosity and specific gravity drilling fluid. The TSB8×6×14 centrifugal sand pump applies to over 3000-meter-long drilling rigs. The TSB8×6×11 centrifugal sand pump applies to under 3000-meter-long drilling rigs, also can be can be used to supply mud to triplex mud pump as a filling pump. The TSB6×5×11 centrifugal sand pump applies to truck-mounted drilling rigs or pocket drilling rigs. The TSB4×3 centrifugal sand pump is usually used as measuring pump or replenishment pump. The TSB3×2 centrifugal sand pump is usually used as clean water pump.
On inquiries and orders please specify:
n Centrifugal Pump Model
n With motor or not
n Impeller Size
Model | Rotation Speed R/Min | Capacity | Pressure Head/m | Efficiency | Motor HP. | Weight |
TSB10×8×14 | 1450/1750 | 280-320 | 33-38 | 65 | 75/90 | 1150/1300 |
TSB8×6×14 | 1450/1750 | 240-260 | 33-35 | 65 | 55/75 | 830/1100 |
TSB8×6×11 | 1450/1750 | 220-240 | 24-26 | 65 | 37/45 | 700/750 |
TSB6×5×14 | 1450/1750 | 180-240 | 26-33 | 65 | 37/45/55 | 700/750 |
TSB6×5×11 | 1450/1750 | 160-170 | 24-26 | 65 | 30/37 | 655/687 |
TSB5×4×14 | 1450/1750 | 120-150 | 28-33 | 65 | 22/30/37 | 510/550 |
TSB4×3×13 | 1450/1750 | 60-80 | 26-33 | 65 | 11/15 | 395/405 |
TSB3×2×13 | 1450/1750 | 40-60 | 24-35 | 65 | 7.5/11/15 | 335/385 |
Its main parts are pump shell, impellers, bearing block, pump axle, bearing, shaft coupling,wearing plate, seal apparatus, oil seal, motor and base.
The Series Centrifugal Sand Pump has these features:
(1)open impeller, apply to transport high viscosity drilling liquid.
(2)combination seal for a long service life.
(3)use universal bearing houses and bearings, convenient to maintain and cut the costs.
(4)the major parts are made from antiwear nodular iron, and long service life.
